DESCRIPTION

Basic Info.

Model NO.	JD-3001
Dimension	950*120*130cm
Printing Color	1 Color
Printing Speed	14m/Min/Tape
Printing Area	800*280mm
Transport Package	Plywood Wooden Case Packing
Specification	CE Certificate
Trademark	JINGDA
Origin	China
HS Code	8443192290
Production Capacity	10 Sets/Month

Product Description

(JD-3001) Roll to Roll Automatic Label Silk Screen Printing Machine for Textile Lifting Belt / Seat Belt / Gift Belt

Specifications

Woven Trademark With Silk Screen Printed LogoNew Product for one color label screen printing machine/label printing press

Characteristics :

· With CNC servo feeder, it can print the materials of unlimited size

· The servo controller for doctor set the length with digit.

· The printing speed: 5 m/min

· It is suitable for all kinds of hand soft materials and roll packing materials such as Satin labels, Ribbon label, taffeta labels, Cotton Labels, Elastic band, Polyester cotton, nonwoven label. It can print simultaneously up to several ribbons in same time which larger increase your printing capacity

· Print bottom colors or thin characters in large area, clear net spot without colors fading.

· It can print exactly white color even on dark ribbons

· User friendly designed touch screen monitor is installed

· Sensor is installed in the machine to detect the ribbons, can printing front and back side in the same colors. Or the second time printing.

· Vacuum pump function is available to secure fixing of ribbons throughout the entire printing cycle or intermittently.

· cycle blowing drying oven is used to keep in the materials dryer quickly.

· Cleaning shoot up for the doctor blade shelf

· This model just takes a little space.

Main Technical Variables :

Printing Area	Printing Speed	Printing Function	Power, Rate	Weight	Dimension
800*280mm (Length x Width)	14m/min/tape	2 Colors	380V/16.6KW	2.6T	950*120*130cm
800*280mm (Length x Width)	14m/min/tape	3 Colors	380V/21KW	3.4T	1250*120*130cm
800*280mm (Length x Width)	14m/min/tape	4 Colors	380V/25.3KW	4.2T	1500*120*130cm
800*280mm (Length x Width)	14m/min/tape	5 Colors	380V/29.7KW	5T	1800*120*130cm

Printed Samples:

Packaging & Shipping

Packaging Detail: Export wooden case packing

Payment: T/T 50% deposit prepaid and the balance paid before shipment.

Delivery Time: After receiving the balance.

Company Information

Rui'an Jingda Printing Machinery Co., Ltd. mainly specializes in designing and manufacturing cloth tape label printing machines, silk screen label printing machines and press accessories as well, which are widely applied to printing labels for garment label, textile accessories, medical products, foodstuff and supermarkets. We are an enterprise integrating development, research, manufacture, trade and service.

With our abundant and strong technical capabilities and advanced equipment, we have established a perfect quality control system. Jingda provide the best fully precise printing technology. Jingda equipment on behalf of full processed flexibly, from flexographic printing machine to screen label printing, our machinery can content with all kinds of label tapes and roll materials.

Our service is considered more carefully, and we provide counseling, training. This is lead of Jinda in label printing machinery industry.
